Product Name:Magnetic Card ReaderProduct Model:MSR100U/MSR90U
Description:
USB interface to keyboard buffer, reads 3 tracks of data. Designed for PC laptops.
Color is white. Windows programming disk supplied.
Item specifics:
Cable: USB Cable , really Plag and Play
Format: ISO7811,12,13 Credit Card, gift card, all other standard
magnetic cards
And all 1,2,3 Tracks readable
Additional: Drivers Licenses readable
Dimensions (LxWxD): 100 * 34 * 30 mm
Used for Credit Card Point of
Control,
Age Verification from AAMVA Drivers Licenses
Advantage:
Low power consumption, power supplied by computer
Excellent design
CE, RoHS, FCC certificated
Function configurable upon request in factory, best
performance/cost rate
Key Features:
Read 1, 2, 3 tracks
Magnetic Card Standard:ISO8711,Credit,Drivers Lisence
Read only Speed: 10 ~ 150 cm/sec
Power Supply: 5V DC, 700mA
Power: Power supplied by computer
Lifespan of the Magnetic Head: Approx. 300, 000 passes
Display: Operation responded by LED and one buzzer
Interface option: USB
Dimensions (LxWxD): 100 * 34 * 30 mm
Housing: ABS
Weight: 108g
Operating Temperature: -20 to +60
Relative Humidity: 90% non-condensing
Certification: CE FCC ROSH
WARRANTY
One-year warranty of defects in material and functionality to the original
purchasers. Within the warranty period, if the product found to be defective will
be repaired or replaced. This warranty applies to the products only under the
normal use of the original purchasers, and in no circumstances covers
incidental or consequential damages through consumers’ misuse or
modification of these magnetic stripe products.
